50kW Digital radiography System

More Views

50kW Digital radiography System

Code:

50kW Digital radiography System

This 50kW Digital radiography System uses KODAK VHD CCD by way of camera shot sensor, KODAK VHD CCD mainly uses in the outer space scientific research, has the superelevation sensitivity and extremely reliability, ultra long service life, This DR system CCD detector compares with ordinary CCD detector has a higher sensitivity and more superior image quality, compares the flat detector has the longer service life and a higher reliability, higher spatial resolution and extremely low use-cost.

 This Digital radiography System runs stably and it includes:
 Kodak CCD Digital Detector
 Toshiba X-ray tube
 Canadian High frequency generator
 14X17 Imaging amplifier

Detector features:

1. Tremendous caliber lens technology , enormously reduce the exposure dose.
 2. Intelligent digital image acquisition technology, doctor only need press down the hand brake
 3. High speed image transmissions technology, transmission time not to 2 seconds.
 4. Sensor repairs surgery automatic, Guaranteed the image long-term stable without bad spot and distort
 5. Ultra long service life, theoretically Non- life limit
 6. CSL scintillate screen, image clear and sharpness, other non- CSL product cannot compare with it

Detector performance parameters

Item number	1680A	980A
Imaging Ash	65535rank	65535rank
Imaging Pixels	16,800,000	9,800,000
Resolution	4.6LP/mm	3.6 LP/mm
Image Bright	≥12rank	≥12rank
Active Image Size	14×17inch	14×17inch
Processed Image Display	≤15s	≤10s
Bit Depth	16bit	16bit

Image acquisition workstation Specification:

3.0G CPU, 17 inch high resolution LCD, 1G memory, 80G hard disk, 100M net card, DVD-R/RW

Allocation Table

Description	specification and explanation
500mA high-frequency X-ray	32-50kw high frequency generator
	Toshiba tube
	360expansion U style of arm and flat bed
	gridratio:1:8 180line/inch 1.8m/1.0m
	Manual Collimator
	Console the programmable exposure technology contains 99 kind of procedures
image detector	1680A / 980A
Vertical Stand Dedicated power	12V Vertical Stand Dedicated
USB Data transmission line	12.8 meters high-speed USB Data transmission line
Image acquisition workstation (lowest configuration:)	3.0G CPU, 17 inch high resolution LCD, 1G memory, 80G hard disk, 100M net card, DVD-R/RW
Image acquisition software	Patient registration image acquisition cutting negative imageimage turning over revolving contraction and release tagging translation demonstration image window width and position adjustmentdicom image transmission dicom film printing worklist function statistical inquiry image dedicated processing technology
Image processing technology for special-purpose	Dynamic range optimization technology automatically carries on the compression on the primitive image dynamic curve, achieving image characteristic that doctor is familiar with,being convenient to diagnosis.
	High-frequency image enhancement technology strengthen image contrast, enhance detail resolution, remarkably enhance high-frequency image quality of the bone trabecula, demonstrating more perfect. Noise abatement technology: automatically filtrate mixed frequency signal data, obviously reduces the image noise, Enhance image signal noise ratio, improved the image quality.
	Edge enhancement technology:automatically diagnostic and analytic image data, enhance image edge sharpness to make the image clearly.
Digital image workstation software	DICOM receiving, transmission, inquiry, storage, film printing, report printing
ZK-PACS/RIS and IBM server	including the whole function of PACS/RIS
Dry type camera	KodakSony FUJI
