20kW/200mA Medical high frequency diagnostic x-ray machine

20kW/200mA Medical high frequency diagnostic x-ray machine

More Views

20kW/200mA Medical high frequency diagnostic x-ray machine

Code:
20kW/200mA Medical high frequency diagnostic x-ray machine

Technical Specifications
CONTENTS JYSX0314
Intermittent mode 100kV, 200mA, 20kW
Power voltage 380V±10% 50Hz±10%
Tube current Radiography 16mA~200mA
Output voltage Radiography 40-125KV  step by 1kV;
resistance power less than 0.5Ω
Output power 20kW
Exposure time Radiography 0.0025s~6.4s adjustable
Nominal frequency 30kHz
Anode rotating speed 2800r/min
Anode heat capacity 140KHU
Focus Small focus:1.0mm  Big focus:2.0mm
Length*width*height of bed surface 2000mm×750mm×690mmDeviation:±10mm
Horizontal movement distance (table) ≥200mm
Vertical movement distance (table) ≥900mm
Distance from table surface to film 50mm±2mm
Distance of vertical movement 770mm±10mm;
Moving crosswise (left & right) +180°~-180°deviation<±2°
Moving lengthway
(Along ground railway)		 ≥1300mm
Fixed beam filtration grid density ≥40 lines/cm.
Grid ratio 10:01
Focus distance 100cm
Cassette size 5″×7″ 8″×10″ 10″×12″ 11″×14″ 14″×17″

 Configuration
No Components Qty
1 X-ray tube 1
2 Radiographic table 1
3 Collimator 1
4 Microcomputer console 1
5 High-voltage generator, 1
6 High-voltage cable 2
7 Vertical bucky stand 1
Description

Details

20kW/200mA Medical high frequency diagnostic x-ray machine

Technical Specifications
CONTENTS JYSX0314
Intermittent mode 100kV, 200mA, 20kW
Power voltage 380V±10% 50Hz±10%
Tube current Radiography 16mA~200mA
Output voltage Radiography 40-125KV  step by 1kV;
resistance power less than 0.5Ω
Output power 20kW
Exposure time Radiography 0.0025s~6.4s adjustable
Nominal frequency 30kHz
Anode rotating speed 2800r/min
Anode heat capacity 140KHU
Focus Small focus:1.0mm  Big focus:2.0mm
Length*width*height of bed surface 2000mm×750mm×690mmDeviation:±10mm
Horizontal movement distance (table) ≥200mm
Vertical movement distance (table) ≥900mm
Distance from table surface to film 50mm±2mm
Distance of vertical movement 770mm±10mm;
Moving crosswise (left & right) +180°~-180°deviation<±2°
Moving lengthway
(Along ground railway)		 ≥1300mm
Fixed beam filtration grid density ≥40 lines/cm.
Grid ratio 10:01
Focus distance 100cm
Cassette size 5″×7″ 8″×10″ 10″×12″ 11″×14″ 14″×17″

 Configuration
No Components Qty
1 X-ray tube 1
2 Radiographic table 1
3 Collimator 1
4 Microcomputer console 1
5 High-voltage generator, 1
6 High-voltage cable 2
7 Vertical bucky stand 1
