High Cost-effective 3.5KW Mobile Bedside Medical X-ray Machines

High Cost-effective 3.5KW Mobile Bedside Medical X-ray Machines

More Views

High Cost-effective 3.5KW Mobile Bedside Medical X-ray Machines

Code:

High Cost-effective 3.5KW Mobile Bedside Medical X-ray Machines


 Characteristics:
 1. More personalized in mechanical and convenient in position without dead corner. With fully consideration of operating convenience, the product is awarded "National Practical New-type Patent License".
 2. Cantilever Type: active movement and resonable structure.
 3. Especially suitable in dedicated photography, on-board examination and mobile examing photography.

 Main Technical Parameter:

Model	JYSX0504
Power voltage	A.C. 220±22V
Power frequency	50Hz±1 Hz
Power capacity	≥3.5kVA
Power resistance	≤0.6Ω
Maximum tube voltage	110kV
Maximum tube current	70mA
Inverting frequency	50Khz
Rated output power	3.5kW
Tube voltage	40~110kV
Accumulate of current	0.5mAs~200mAs 40 grades Adjustable
Focus	1.5mm
Rotary speed of anode	2800r/min
Beam limiter	Light-spot positioning beam limiter
Exposure mode	Manual and wireless control
Back and forth movement of arm	500~1100mm
Pillar Rotation	360°
Upper and lower movement of X-ray resource components	680~1850mm
Rotation of X-ray resource components around the axes	±90°
Rotation of X-ray resource components around the arm	±90°
Self-Rotation of X-ray resource components around the axes	210°

Description

Details

High Cost-effective 3.5KW Mobile Bedside Medical X-ray Machines


 Characteristics:
 1. More personalized in mechanical and convenient in position without dead corner. With fully consideration of operating convenience, the product is awarded "National Practical New-type Patent License".
 2. Cantilever Type: active movement and resonable structure.
 3. Especially suitable in dedicated photography, on-board examination and mobile examing photography.

 Main Technical Parameter:

Model	JYSX0504
Power voltage	A.C. 220±22V
Power frequency	50Hz±1 Hz
Power capacity	≥3.5kVA
Power resistance	≤0.6Ω
Maximum tube voltage	110kV
Maximum tube current	70mA
Inverting frequency	50Khz
Rated output power	3.5kW
Tube voltage	40~110kV
Accumulate of current	0.5mAs~200mAs 40 grades Adjustable
Focus	1.5mm
Rotary speed of anode	2800r/min
Beam limiter	Light-spot positioning beam limiter
Exposure mode	Manual and wireless control
Back and forth movement of arm	500~1100mm
Pillar Rotation	360°
Upper and lower movement of X-ray resource components	680~1850mm
Rotation of X-ray resource components around the axes	±90°
Rotation of X-ray resource components around the arm	±90°
Self-Rotation of X-ray resource components around the axes	210°
