"Medberg" MB-36:

More Views

Code:

Main Applications

Technical Features:

Housing	MS Powder Coated, SS Top on two wheels
Max. Vacuum / LPM	-700 mm Hg, 25 Ltrs / min
Pump Type	Single Rotary Vane Pump
Jars	2 x 2 Ltr. PC Jar
Filter	Trap Filter
Tubing	8 mm ID x 2 mtr. (PVC)
Vacuum Gauge	6.5 cm dia 0-760 mm Hg
Power Supply	220 V AC, 50 / 60 Hz, 180 Watt
Noise Level	55 dB A ± 3
Dimensions	43 x 30 x 62 cms
Net Weight	24 Kg
Overflow Safety	Mechanical
Accessories / Optional	110 V on request
Certifications	CE, IEC 60601-1

Ordering Information:

Catalogue No.	Model
MB-36	"Medberg" MB-36:

Description

Main Applications

Technical Features:

Housing	MS Powder Coated, SS Top on two wheels
Max. Vacuum / LPM	-700 mm Hg, 25 Ltrs / min
Pump Type	Single Rotary Vane Pump
Jars	2 x 2 Ltr. PC Jar
Filter	Trap Filter
Tubing	8 mm ID x 2 mtr. (PVC)
Vacuum Gauge	6.5 cm dia 0-760 mm Hg
Power Supply	220 V AC, 50 / 60 Hz, 180 Watt
Noise Level	55 dB A ± 3
Dimensions	43 x 30 x 62 cms
Net Weight	24 Kg
Overflow Safety	Mechanical
Accessories / Optional	110 V on request
Certifications	CE, IEC 60601-1

Ordering Information:

Catalogue No.	Model
MB-36	"Medberg" MB-36:
