TWO TANK INTERACTING SYSTEM

TWO TANK INTERACTING SYSTEM

More Views

TWO TANK INTERACTING SYSTEM

Code:
DESCRIPTION:
The setup studies behaviour of multi capacity process when connected in interaction mode. It consists of supply tank, pump for water circulation, Rotameter for flow measurement, two independent process tanks with scales connected in interacting mode. The components are assembled on frame to form tabletop set-up.

EXPERIMENTATION:
  • To obtain experimentally the step response and to compare the experimental and theoretical responses
UTILITIES REQUIRED:
  • Water supply
  • Floor Drain
  • Electrical supply : 1 Phase,220V AC, 0.5kw
  • Stop Watch
  • Table for set-up support.
TECHNICAL DETAILS:
Process Tank Material SS, Circular, with graduated level scale (2Nos.)capacity 2.5 to 3.5 litres.
Supply Tank Material Stainless Steel, Capacity 20 litres.
Overhead tank Material Stainless Steel, Capacity 5 litres.
Water Circulation FHP Pump, Tullu/Standard make.
Piping SS/PVC, size ¼”
Flow Measurement Rotameter.
An ENGLISH instruction manual will be provided along with the Apparatus
The whole set-up is well designed and arranged on a rigid structure painted with industrial PU Paint.

Ordering Details:
Catalogue No Description
JIPC-016 TWO TANK INTERACTING SYSTEM


Description

Details

DESCRIPTION:
The setup studies behaviour of multi capacity process when connected in interaction mode. It consists of supply tank, pump for water circulation, Rotameter for flow measurement, two independent process tanks with scales connected in interacting mode. The components are assembled on frame to form tabletop set-up.

EXPERIMENTATION:
  • To obtain experimentally the step response and to compare the experimental and theoretical responses
UTILITIES REQUIRED:
  • Water supply
  • Floor Drain
  • Electrical supply : 1 Phase,220V AC, 0.5kw
  • Stop Watch
  • Table for set-up support.
TECHNICAL DETAILS:
Process Tank Material SS, Circular, with graduated level scale (2Nos.)capacity 2.5 to 3.5 litres.
Supply Tank Material Stainless Steel, Capacity 20 litres.
Overhead tank Material Stainless Steel, Capacity 5 litres.
Water Circulation FHP Pump, Tullu/Standard make.
Piping SS/PVC, size ¼”
Flow Measurement Rotameter.
An ENGLISH instruction manual will be provided along with the Apparatus
The whole set-up is well designed and arranged on a rigid structure painted with industrial PU Paint.

Ordering Details:
Catalogue No Description
JIPC-016 TWO TANK INTERACTING SYSTEM
