DESCRIPTION:

The setup studies behaviour of multi capacity process when connected in non- interaction mode. It consists of supply tank, pump for water circulation, Rotameter for flow measurement, two independent process tanks with scales connected in non-interacting mode. The components are assembled on frame to form tabletop set-up.

EXPERIMENTATION:

• To obtain experimentally the step response and to compare the experimental and theoretical responses

UTILITIES REQUIRED:

• Water supply
• Floor Drain
• Electrical supply : 1 Phase,220V AC, 0.5kw
• Stop Watch
• Table for set-up support.

TECHNICAL DETAILS:

Ordering Details:
